Caldwell Chameleon XC Series Anamorphic Primes
The Caldwell Chameleon Anamorphic prime lenses offer a retro anamorphic look with modern mechanics. The entire 1.79x squeeze set, 48mm, 60mm, 75mm, 90mm, 112mm, & 150mm will cover full frame sensors and offer the traditional optical aberrations and flare characteristics unique to front anamorphic lenses. The Chameleon Primes employ a Stokes focus system that creates a fairly unique focusing experience compared to many other anamorphic primes. The aesthetic result is the compression of the subject in the vertical plane only. This creates an artistic “attention pull” without creating a “zoom” effect as well. Also, this system helps maintain a constant anamorphic compression across the entire field of view. This more uniform compression helps reduce the “mumps syndrome” that occurs in many other anamorphic lens designs. The complete set can also be converted to Super 35 coverage for cinematographers hoping to capture more edge aberration and optical character on smaller formats.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 48mm T3 2’7” 114mm 6 60mm T3 2’7” 114mm 6 75mm T3 2’7” 114mm 6 90mm T3 2’7” 114mm 6 112mm T3 2’7” 114mm 6 150mm T3 2’7” 114mm 6 -
Cooke Anamorphic 1.8x Full Frame Plus Primes
Cooke’s full frame anamorphic prime’s feature a 1.8x squeeze factor to allow these lenses to fully cover large format sensors like those found in the ALEXA LF and Sony Venice. These lenses produce Cookes warm color pallet with unique anamorphic effects caused by the uncommon squeeze factor. They also feature the Cooke i/Data protocol for sending lens metadata to the camera system.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 32mm T2.3 2' 11" 136mm 9.2lbs 40mm T2.3 2' 11" 136mm 9.7lbs 50mm T2.3 2' 9" 110mm 8.8lbs 75mm T2.3 3' 3" 110mm 7.7lbs 85mm Macro T2.8 22" 136mm 11.4lbs 100mm T2.3 3' 10" 110mm 8.4lbs 135mm T2.3 4' 10" 110mm 11lbs 180mm T2.3 6' 6" 110mm 13.6lbs -
Cooke Anamorphic 1.8x Full Frame SF Primes
Cooke’s full frame anamorphic prime’s feature a 1.8x squeeze factor to allow these lenses to fully cover large format sensors like those found in the ALEXA LF and Sony Venice. These lenses produce Cookes warm color pallet with unique anamorphic effects caused by the uncommon squeeze factor. They also feature the Cooke i/Data protocol for sending lens metadata to the camera system.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 32mm T2.3 2' 11" 136mm 9.2lbs 40mm T2.3 2' 11" 136mm 9.7lbs 50mm T2.3 2' 9" 110mm 8.8lbs 75mm T2.3 3' 3" 110mm 7.7lbs 85mm Macro T2.8 22" 136mm 11.4lbs 100mm T2.3 3' 10" 110mm 8.4lbs 135mm T2.3 4' 10" 110mm 11lbs 180mm T2.3 6' 6" 110mm 13.6lbs -
Scorpio Full Frame 2x Anamorphic Primes
Servicevision made the Scorpio Anamorphic Primes for use with large format cameras, perfect for use with the Sony Venice, RED Monstro, or ALEXA LF sensors. The Scorpio Anamorphics produce excellent field sharpness, warmth, and close focus not found in most anamorphic designs. The set requires a 2.39:1 crop of the full frame sensor area.
**20mm does not cover FF*25mm requires a 15% reduction*35mm requires a 10% reduction*40mm requires a 5% reductionFocal Length Aperture Close Focus Front Diameter Weight (lbs) 20mm** T2.8 1'3' 95mm n/a 25mm* T2.2 1'6" 95mm 5.5 35mm* T2.2 1'6" 95mm 4.8 40mm* T2.2 1'8" 95mm 4.8 50mm T2.2 1'10" 95mm 4.8 60mm T2.8 12" 95mm 5.7 75mm T2.2 2'6" 95mm 4.8 100mm T2.2 3'3" 95mm 4.8 135mm T2.8 4'3" 95mm 5.5 150mm T2.8 5' 95mm 5.5 -
Xelmus Apollo Anamorphic Primes
Xelmus Anamorphics are 2x full frame anamorphic lenses designed in Ukraine. They exhibit some characteristics similar to vintage anamorphics such as Todd-AO or Cineovision, but with more sharpness, less focus fall off, and a more modern mechanical design. Their flares are a cool temperature with fractal diffraction spikes and vertical and horizontal elements. They render an almost watercolor like background when defocused, and produce attractive oval bokeh. Please note that the 32mm does not color full frame, and is Super35 only. The rest of the set is fully compatible in 2.39 on full frame sensors.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 32mm T2 15" 114mm 3.92 40mm T2 15" 114mm 3.88 50mm T1.7 16" 104mm 3.94 60mm T1.7 16.5" 104mm 3.96 75mm T2 21" 104mm 4.32 100mm T2.3 17.5" 104mm 4.56 135mm T2.8 29.5" 104mm 5.48
