Century S 2000 MK II Periscope T4.0
While ideal for tabletop and miniature work, the Century S2000 Mark II periscope can achieve a wide variety of unique perspectives in hard to reach places. The relay systems ultra low dispersion glass and fast T4 stop will maintain the excellent image quality of the wide variety of lenses that can be used. The system is available in 90 degree and strait view probe configurations and focus and iris controls are on the main body.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) Relay T4 N/A N/A 8.8 lbs | 17.5" Long Extender module N/A N/A N/A 2.8 lbs | 5.25" Long 90-degree module N/A N/A N/A 2.4 lbs | 4" Long Horiz. + 6" Long Vert. -
Clairmont Baby Periscope
The compact Baby Periscope was designed to be much shorter than the Century 2000 Periscope so that it can get into places that were not previously possible. Like its counterpart it was designed to allow the user to extend the lens away from the camera to get viewpoints that could not otherwise be accomplished. It can be configured with a straight relay as well as with a right angle attachment.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) Relay T4 N/A N/A 8.8 lbs | 10" Long -
Innovision Probe II Plus T6.3
The Innovision Probe II Plus is a faster, T6.3, optically improved follow up to their original probe system. It’s very small diameter makes the Probe II Plus well suited for tabletop and miniature work and offers a number of lenses plus a 90-degree relay.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) Relay T6.3 N/A N/A 3.6 lbs | 20.5" Long Extender Module N/A N/A N/A 0.8 lbs | 5.5" Long Low-Angle Prism N/A N/A N/A 0.6 lbs | 2.5" Long 45-degree module N/A N/A N/A 1 lbs | 3.75" Long Horiz. + 3" Long Diag. 90-degree module N/A N/A N/A 0.6 lbs | 2.25" Long Horiz. + 2.7" Long Vert. -
Laowa Probe
Venus Optics Laowa 24mm f/14 Probe features an integrated lens light for illuminating the subject using the slow f/14 stop. The probe is extremely sharp and allows focusing millimeters away from an object. It is available in PL mount and covers large format sensors.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 24mm T14 20mm (from front of system) N/A 1.04 lbs | 16" Long -
Laowa Pro2be
The Laowa 24mm T8 Pro2be is the second generation of Laowa probe. It offers a faster stop than the old model, with a larger, more robust design. It’s tack sharp, full frame compatible, and allows up to 2x macro magnification. The housing is waterproof up to 36cm from the front of the system.
Three housing types are available: Straight, 35-degree relay, and Periscope relay.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 24mm Straight 8 4mm (from front of system) N/A 2.28 lbs 24mm 35-degree Relay 8 4mm (from front of system) N/A 2.25 lbs 24mm Periscope Relay 8 4mm (from front of system) N/A 2.35 lbs -
Optex Excellence Probe T5.6
The Optex Excellence is one of the best probe systems made. Optically sharp and fast enough for shooting in less than ideal lighting environments, the Optex uses its own unique lenses to create beautiful images.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) Relay T5.6 N/A N/A 6.2 lbs | 16.75" Long Probe extension N/A N/A N/A 2.2 lbs | 10.75" Long 90-degree module N/A N/A N/A 1 lbs | 4.25" Long Horiz. + 3.75" Long Vert. 10mm N/A 2' 11" 46mm 0.8 lbs 14mm N/A 2' 11" 46mm 0.8 lbs 20mm N/A 2' 11" 46mm 0.7 lbs 28mm N/A 3' 1" 46mm 0.6 lbs -
Revolution Lens System T7.5
The Revolution is a unique snorkel lens designed to allow live panning of the taking lens while maintaining a level horizon. The system can also rotate the image 360 degrees while shooting. This tool opens up many creative opportunities. Standard PL Mount lenses can be mounted to the Revolution. The system also has its own specialty mini lenses for tight shooting environments. The entire system is geared for use with motorized follow focus systems.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) Relay T7.5 N/A N/A 7.8 lbs | 13.25" Long PL Swivel N/A N/A N/A 5 lbs | 5.25" Long Horiz. + 10.5" Long Vert. + 4.25" Long Horiz. Mini PL Swivel N/A N/A N/A 4.4 lbs | 6" Long Horiz. + 9" Long Vert. + 3" Long Horiz. PL Horizon Tracker N/A N/A N/A 3.2 lbs | 15.75" Long Horiz. + 4.5" Long Vert. Mini PL horizon tracker N/A N/A N/A 2.4 lbs | 11" Long Horiz. + 2.75" Long Vert. Borescope N/A N/A N/A 2 lbs | 9.75" Long Mini PL Borescope N/A N/A N/A 1.6 lbs | 8.6" Long -
SKATER Scope Snorkel Lens System
The P+S Skater Scope T5.6 is a compact periscope that allows straight borescope and multi angle periscope cinematography without the need to swap components. In addition, the 360 degree image rotating prism offers additional perspective creativity. The rear macro focus function will extend any lenses’ close focus into macro. The system is compact enough to fit into many tight situations, yet extends the taking lens far enough to eliminate camera lighting shadow. NOTE: This system CANNOT be live panned during a shot and maintain a level horizon.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) Module T5.6 N/A N/A 7.3 lbs + lens | Length 13.2" + lens -
T-Rex Lens System
The P+S T-Rex Periscope Relay System is about the most versatile self contained unit available. At T7.1, the unit allows you to pan left and right while maintaining a level horizon without the use of external motors. The multi-angle orientable taking lens module allows the cinematographer to capture almost any unusual perspective. The 360 degree image rotating prism adds even more creative possibilities. In addition, use of the proprietary lenses gives you built in zoom capability from 5.5mm fisheye to 112mm depending upon the lens used. Also, the straight borescope module can be installed in place of the swivel module, increasing the system speed to T5.6.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) Relay with Borescope T5.6 N/A N/A 15.8 lbs | 33" Long Relay with Swivel Module T7.1 N/A N/A 20.8 lbs | 24" Long Horiz. + 7" Long Vert. + 5" Long Horiz. Borescope N/A N/A N/A 5 lbs | 20" Long Swivel module N/A N/A N/A 9.8 lbs | 10" Long Horiz. + 7" Long Vert. + 5" Long Horiz. 5.5-20mm N/A 2' 10" with swivel | 3' 3" with borescope 68mm 1 lbs 8-18mm N/A 2' 11" with swivel | 3' 4" with borescope 84mm 1 lbs 17-36mm N/A 3' with swivel | 3' 5" with borescope 75mm 1 lbs 32-70mm N/A 3' 3" with swivel | 3' 8" with borescope 63mm 0.5 lbs 55-112mm Macro N/A 3' 8" with swivel | 4' 1" with borescope 75mm 1.6 lbs
