RED DSMC3 V-Raptor 8K VV
The V-Raptor is the first DSMC3 camera from RED. It features the new V-Raptor 8K VV large format sensor, boasting 17+ stops of dynamic range and a maximum frame rate in 8K 17:9 of 120FPS. The DSMC3 platform is more compact than the previous DSMC2 platform, offering filmmakers a more versatile package.
Sensor Size: VV - 40.96 x 21.60mm
Maximum Resolution: 8K
Sensor Frame Rates: 1-480 FPS (120 FPS @ 8K 17:9)
Weight: 4.03 lbs (Body Only)
ARRI Signature Zooms
ARRI designed the Signature Zooms to perfectly match the Signature Prime set of lenses. Built with LPL mounts for optimal full frame performance, the 16-32mm T2.8, 45-135mm T2.8, and 65-300mm T2.8 zooms are both fast and well-balanced for their size. They feature the same pleasing bokeh, smooth focus, and the warm cinematic tone of the prime lens set.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 16-32mm T2.8 7.6" 156 mm 7 45-135mm T2.8 3'4" 114 mm 8.25 65-300mm T2.8 6' 156 mm 17.13
MasterBuilt Anastigmat Prime
The MasterBuilt Anastigmat is a single 160mm focal length prime that provides a sharp, even image with attractive focus roll off and a warm aesthetic flare, with minimal chromatic aberration. The lens renders a painterly background and a sharp foreground. Available in LPL mount only.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 160mm T1.8 4'7" 114mm 6.4 lbs
MasterBuilt Portrait Primes
The Portrait series of the MasterBuilt family of lenses exhibit a more dramatic focus fall off and slightly lower contrast than the original lenses, creating a dreamy portrait look. They have a similar color temperature and vintage feel like the rest of the MasterBuilts and are available in three focal lengths. They also feature the same fast t-stops and uniform construction as the rest of the set.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 32mm T1.4 16" 114mm 4.2 lbs 55mm T1.4 19" 114mm 4.6 lbs 100mm T1.4 3' 9" 114mm 5.5 lbs
Musashi Takumi Zooms
The Musashi Optics made Takumi Full Frame Zooms are available in 20-129mm T2.9 and 40.6-332mm T4.8 and feature clean, flat images with excellent flare reduction and even illumination on full frame sensors. The 9 blade round iris renders smooth bokeh with slightly peaked edges.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 29-120mm T2.9 4' 136mm 16.5 lbs 40.6-332mm T4.8 4'1" 136mm 20.3 lbs
Sony Venice 2
The Sony Venice 2 introduces a 8.6K Full Frame sensor with dual 800 and 3200 base ISO modes. It features the same built-in full spectrum ND filters as the original Venice. The R7 Raw Recorder is now built into the body of the camera, foregoing the use of SxS cards and proxy recording for the more robust X-OCN raw codec. The first generation 6K sensor module from the Venice is compatible with the Venice 2 as well.
Sensor Size: Large Format – 35.9mm x 24.1mm
Maximum Resolution: 8.6K
Sensor Frame Rates with 8.6K Module: 1-90 FPS (30 FPS @ 8.6K Full Frame)
Sensor Frame Rates with 6K Module: 1-120 FPS (60 FPS @ 6K Full Frame)
Weight: 9.25 lbs (Body Only)
Nikon - Zero Optik Primes
These Zero Optik Nikon Primes are based on vintage full frame Nikon still photography lenses, but have been rehoused with cinema style gearing on the iris and focus for use on todays modern film sets.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 15mm T4.0 1' 114mm 2.5 lbs 20mm T3.0 10" 114mm 2.5 lbs 24mm T2.2 1' 95mm 1.5 lbs 28mm T2.2 1' 95mm 1.7 lbs 35mm T1.5 TBD 95mm TBD 55mm T1.3 TBD 95mm TBD 58mm T1.3 1' 1" 95mm 2.1 lbs 85mm T1.5 TBD 95mm TBD 85mm T1.9 1' 10" 95mm 2.5 lbs 105mm T1.9 TBD 95mm TBD 135mm T2.1 TBD 95mm TBD
Angenieux Optimo Ultra Compact Zoom
The 37-102mm Angenieux Optimo Ultra Compact is part of a new generation of high-end lenses, fully designed for the FF/VV format. Lightweight and compact, this zoom is among the lightest on the market and has completely new optical design and mechanics. Features well controlled optical performances at each focal length and focus distance by having a good balance between contrast and resolution. It's appealing cinematic look has low distortion, no ramping, minimal breathing, and also has a close focus of 2ft / 0.6m, enabling extreme close-up shots.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 37-102mm T2.9 2 ft 114mm 5.7 lbs
IB/E Raptor Macros
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 60mm T2.9 (T5.3 at Close Focus) 7.48" 95mm 2.54 lbs 100mm T2.9 (T5.3 at Close Focus) 12.3" 95mm 3.3 lbs 150mm T2.9 (T5.3 at Close Focus) 15" 95mm 4.2 lbs 180mm T2.9 (T5.3 at Close Focus) 18.5" 95mm 6.4lbs
Caldwell Chameleon XC Series Anamorphic Primes
The Caldwell Chameleon Anamorphic prime lenses offer a retro anamorphic look with modern mechanics. The entire 1.79x squeeze set, 48mm, 60mm, 75mm, 90mm, 112mm, & 150mm will cover full frame sensors and offer the traditional optical aberrations and flare characteristics unique to front anamorphic lenses. The Chameleon Primes employ a Stokes focus system that creates a fairly unique focusing experience compared to many other anamorphic primes. The aesthetic result is the compression of the subject in the vertical plane only. This creates an artistic “attention pull” without creating a “zoom” effect as well. Also, this system helps maintain a constant anamorphic compression across the entire field of view. This more uniform compression helps reduce the “mumps syndrome” that occurs in many other anamorphic lens designs. The complete set can also be converted to Super 35 coverage for cinematographers hoping to capture more edge aberration and optical character on smaller formats.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 48mm T3 2’7” 114mm 6 60mm T3 2’7” 114mm 6 75mm T3 2’7” 114mm 6 90mm T3 2’7” 114mm 6 112mm T3 2’7” 114mm 6 150mm T3 2’7” 114mm 6
Atlas Orion Anamorphic Primes - Silver Edition
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 32mm T2 1.75" 114mm 4.7 40mm T2 2' 114mm 5.2 50mm T2 2.5" 114mm 5 65mm T2 2.75" 114mm 5 80mm T2 3' 114mm 6 100mm T2 3.5" 114mm 6.7
Olympus - Zero Optik Primes
The Zero Optik Olympus Primes are a set of rehoused still photography lenses from the 1970’s. Unique among photo lenses for their combination of compact size, uniform T2.2 apertures, and consistent performance. They produce sharp images with warm smooth flares, without being too sterile.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 21mm T2.2 8" 95mm 1.3 lbs 24mm T2.2 10" 95mm 1.6 lbs 28mm T2.2 1' 95mm 1.5 lbs 35mm T2.2 9" 95mm 1.4 lbs 40mm T2.2 11" 95mm 1.3 lbs 50mm T1.2 11" 95mm 1.8 lbs 85mm T2.2 2'6" 95mm 2.1 lbs
Angenieux Optimo Primes
Angenieux's new Optimo Primes offer filmmakers small lightweight full frame cinema primes made specifically to match Angenieux's line of cinema zooms. The Optimo Primes feature a unique design that allows the iris assembly, an internal glass element, and a rear filter to be swapped out, providing filmmakers with a versatile tool for creating dynamic images. The lenses are fast ranging from T1.8 for most focal lengths to T2 and T2.2 for the 18mm and 200mm respectively. Each lens features Cooke i/Data and ARRI LDS for lens metadata capture.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 18mm T1.8 1'2" 95 mm 4.2 21mm T1.8 1'2" 95 mm 3.96 24mm 1.2' 1'2' 95 mm 3.7 28mm T1.8 1'2" 95 mm 3.75 32mm T1.8 1'2" 95 mm 3.75 40mm T1.8 1'2" 95 mm 3.75 50mm T1.8 1'4" 95 mm 3.75 60mm T1.8 1’2″ 95 mm 3.75 75mm T1.8 2' 95 mm 3.75 100mm T1.8 2’4” 95 mm 3.96 135mm T1.8 3'3" 95 mm 4.4 200mm T2.2 4' 114 mm 5.1
Leitz Cine Zooms
The Leitz Cine Zoom set consists of the 25-75mm and 55-125mm. Both zooms are a fast T2.8 and designed to cover full frame formats. They are color matched with the Leitz Primes and feature no light loss over the entire zoom range when zooming. They exhibit exceptionally low distortion, minimal breathing, and no visible chromatic aberration.
Focal Length Aperture Close Focus Front Diameter Weight (lbs) 25-75mm T2.8 3’ 114 mm 8.2 55-125mm T2.8 3’5” 114 mm 9.7
