• Angenieux 6x Zoom - Ancient Optics

    DSC03133 DSC00024 DSC03140

    The Angenieux 6x Multi Format is based on the original 20-120mm from the 1960’s. This version has been fully rehoused by GL Optics for Ancient Optics and features the ability to change format by swapping the rear optic. The lens itself looks very close to the original 20-120mm, producing a sharp image with gradual fall off, lower contrast with blue magenta flares, and smooth bokeh. It pairs well with many prime lens sets from the 40’s, 50’s and 60’s. The standard rear optic 20-120mm T2.9 covers Academy 35, while the 24-144mm T3.6 rear covers Super35 and the 33-198mm T4.9 rear covers Full Frame.

  • Canon FD 3x Zoom - Ancient Optics

    DSC03167 DSC00018

    The Canon FD Zoom is based on the original Canon FD 35-105mm. It has been meticulously rehoused into a modern cinema housing, but still features the same beautiful image produced by the original zoom. This zoom pairs well with the Canon FD or Canon K35 primes and is convertible from its original 35-105mm full frame format down to a Super 35 24-75mm format. This reduces the image circle of the lens, while speeding it up to a T2.9, making it perfect for Super 35. The lens is sharp, with moderate fall off, beautiful textured bokeh, and features Canon’s Super Spectra Coatings that produce gold and purple flares without losing too much contrast.

  • Fuji EBC Primes - Ancient Optics

    DSC03187 DSC00007 v4 DSC03182

    The Fuji EBC Primes were originally released in the 1970’s as compact fast SLR lenses for the still photography market. Fuji used Electronic Beam Coatings (EBC) on these lenses, allowing 11 layers to be coated on the elements, something that was unheard of at the time. The lenses are beautiful, exhibiting gradual fall off, colorful flares, and smooth bokeh. This set has been redesigned into modern housings by Ancient Optics, with matching focus and iris rings and standard front diameters, and PL mounts, making the set easier to use for modern filmmakers.

    Focal Length Aperture Close Focus Front Diameter Weight (lbs)
    19mm 3.8 8" 110mm 1.76
    24mm 2.9 8" 110mm 1.98
    28mm 2.1 12" 110mm 2.2
    35mm 2.1 12" 110mm 1.98
    50mm 1.4 16" 110mm 2.2
    70mm 2.2 18" 110mm 2.64
    100mm 2.9 2'2" 110mm 3.3
    135mm 2.7 3'6" 110mm 3.74
  • Petzvalux Primes - Ancient Optics

    DSC03111 v2 DSC00029 v3 DSC03108 v2 DSC03120

    The Petzvalux are a set of full frame, LPL-mount lenses that feature modern optics based on vintage Petzval lens designs. They feature a “tuning ring” on the front of the lens that provides a tunable Petzval look. This allows the user to tune the intensity of the sharpness, fall-off, and Petzval bokeh effect. This set was designed by Ancient Optics to include additional focal lengths than are normally available in the Petzval family, adding a 27mm, 38mm, and 120mm.

    Focal Length Aperture Close Focus Front Diameter Weight (lbs)
    27mm 1.9 12" 136mm 5.62
    38mm 1.7 14" 114mm 4.52
    44mm (Coming Soon)
    55mm 1.7 2' 114mm 3.64
    66mm (Coming Soon)
    80mm 1.9 2'9" 114mm 4.08
    120mm 1.9 3' 114mm 5.73
  • Phénix Zoom - Ancient Optics

    DSC00020 v2 DSC03144

    The Phénix is a parfocal compact lightweight cinema zoom lens rehoused from the original Tokina 28-70mm AT-X stills lens produced in the early ‘90s and based on Angenieux 28-70mm design. Its zoom range is great for the size and weight, and it covers full frame. The original Tokina design features a relatively complex focus and zoom movements, making it very difficult to rehouse. Iron Glass was able to crack the complexity of the design and successfully rehouse this beautiful lens, retaining its beauty while upgrading it in many necessary ways. The result is a sharp lens with attractive fall off at the edges and textured bokeh. It features a new 15 blade iris design, modern gearing on the focus and iris scales, along with a new robust housing. The Phénix pairs nicely with Canon FD’s, Minolta Rokkor, Leica-R’s, Nikon’s, and many other vintage primes.

    Focal Length Aperture Close Focus Front Diameter Weight (lbs)
    28-70mm 2.7 21" 110mm 3.5
  • Kinoptic Tegea Prime - Ancient Optics

    DSC03130 v2 DSC00011 v2 DSC03127

    This ultra wide vintage prime lens is based on the original Kinoptic Tegea 9.8mm. Rehoused by Zero Optik for Ancient Optics, this 9.8mm is quite clean and produces a very wide image. The Zero Optik rehousing features a new 12 blade iris design, robust modern housing with smooth focus and iris gears, and an amazing close focus of 7 inches. This is without a doubt the best rehousing performed on the Kinoptic Tegea 9.8mm.

    Focal Length Aperture Close Focus Front Diameter Weight (lbs)
    9.8mm 2.3 7.75" 114mm 3.88
  • Series 65 Primes - Ancient Optics (Coming Soon)

    series65 scene2 series65 scene5

    Series 65 are 65mm format prime lenses built from vintage optics into modern housings with LPL mounts, they feature no expanders or gimmicks to achieve 65mm coverage. Designed to work with cameras like the ALEXA 65 Open Gate or Blackmagic URSA 17K 65, the Series 65 are high resolution, have excellent close focus, and produce an image that is rich and vintage without being mushy. All lenses feature the same front diameter, uniform housing design, and modern finish.

    Focal Length Aperture Close Focus Front Diameter Weight (lbs)
    25mm (Coming Soon) 3.6 1'2" 110mm 2.4
    30mm (Coming Soon) 3.6 8" 110mm 3.3
    35mm (Coming Soon) 3.6 8" 110mm 2.54
    45mm (Coming Soon) 3.6 1' 110mm 4.04
    55mm (Coming Soon) 3.6 1'3" 110mm (TBD)
    65mm (Coming Soon) 2.9 1'8" 110mm 3.46
    85mm (Coming Soon) 2.9 1'7" 110mm 3.36
    125mm (Coming Soon) 2.9 2'5" 110mm 4.38
    175mm (Coming Soon) 2.9 5'3" 110mm 5.74
  • STATERA Anamorphic Primes - Ancient Optics

    statera 5 WEB statera 1 WEB

    The Stateras are large format 1.5x anamorphic lenses built from a variety of vintage lenses. Featuring modern housings and a beautiful image that is akin to Todd-AO, Cineovision, Technovision, and Nippon Scope lenses, the Stateras have beautiful oval bokeh with single layer coatings which produce a natural flare that feels less modern and highly saturated. The focusing mechanism minimizes “mumps,” so that faces retain their natural shape during focusing. While the lenses are vintage in their nature, they still retain sharpness very well, and their housings are modern and robust when compared to older anamorphic housings.

    Focal Length Aperture Close Focus Front Diameter Weight (lbs)
    35mm (Coming Soon)
    40mm (Coming Soon)
    50mm 2.1 1'10" 125mm 5.10
    75mm 2.1 1'6" 125mm 5.82
    95mm 2.1 2'3" 125mm 9.10
    135mm 2.1 2'3" 125mm 10.30
  • TAMASHII Primes - Ancient Optics

    DSC000161 DSC03100 DSC03097 DSC03098

    The TAMASHII Primes are reimagined lightweight Japanese vintage primes based on lenses from the 1960’s to 1980’s. They feature modern cinema housings in PL mount engineered by Zero Optik and Ancient Optics with standard front diameter sizes and gear positioning. The set is very well matched and exhibits excellent sharpness wide open with next to no chromatic aberration. Their flares are beautifully multi-colored and their bokeh is smooth and bubbly, with a slight cat's eye. They render the background well without muddling, while keeping subjects in sharp focus, even while wide open.

    Focal Length Aperture Close Focus Front Diameter Weight (lbs)
    22mm 2.2 8" 95mm 1.46
    26mm 2.2 1' 95mm 1.43
    29mm 2.2 1' 95mm 1.71
    36mm 2.3 10" 95mm 1.49
    42mm 2 1'3" 95mm 1.29
    52mm 1.9 1'4" 95mm 1.40
    58mm 1.5 1'7" 95mm 1.51
    88mm 2 1'10" 95mm 2.32
    110mm 2.1 2'6" 95mm 2.49
  • Voigtlander Zoomar - Ancient Optics

    DSC00013 DSC03160

    Originally a still photography zoom from 1959, the Voigtländer Zoomar is a full frame zoom lens that produces a relatively sharp image with gradual fall off, exhibits minimal focus breathing, and has relatively low chromatic aberration for a zoom of its era. The Zoomar is a good match to the Super Baltars, Kowa Prominars, or Canon Rangerfinders due to its older optical design. The modern rehousing was performed by GL Optics and features a modern PL mount, modern gearing, and a robust reliable design.

    Focal Length Aperture Close Focus Front Diameter Weight (lbs)
    36-82mm 3.1 2'9" 136mm 8.3
